HL40063MG LASER DIODE

HL40063MG Laser Diode Specification Summary
Part Number HL40063MG
Wavelength 405 nm
Laser Power 600 mW
Package 5.6 mm
Maximum Operating Temperature 0 to 30 deg.
Pin Configuration LD Only
Polarization Ratio 100:1
Description Multi Mode
HL40063MG Data Sheet Download

Overview of HL40063MG Laser Diode

HL40063MG is a high-power violet laser diode developed by Ushio. Operating at a lasing wavelength of 405 nm, it delivers a continuous wave (CW) optical output power of 600 mW. This multi-mode diode is housed in a 5.6 mm TO-can package, offering reliable performance for various industrial and biomedical applications.​

Key Features:

  • Wavelength: 405 nm (violet)
  • Optical Output Power: 600 mW (CW)
  • Operating Current: 450 to 700 mA
  • Operating Voltage: 3.8 to 4.7 V
  • Threshold Current: 100 to 180 mA
  • Beam Divergence: Parallel to junction: 5° to 25° (Full angle 1/e²); Perpendicular to junction: 30° to 50° (Full angle 1/e²)
  • Transverse Mode: Multiple transverse modes (TE mode oscillation)
  • Package Type: 5.6 mm TO-can
  • Operating Temperature: 0°C to 30°C
  • Storage Temperature: -40°C to 85°C

    • Applications:

  • Direct Imaging for PCB: Utilized in mask-less exposure systems for high-definition circuit patterning
  • Industrial Applications: Employed in precision measurement and inspection systems
  • Biomedical Applications: Serves as a light source in medical diagnostics and therapeutic devices
  • Measurement Systems: Used in various measurement and analysis equipment requiring stable and high-power light sources
